DS18 PRO 6x9" Shallow Water resistant Mid-Range Loudspeaker 250 Watts Rms 2-Ohm (Single Unit)

No review yet. Write Review
Regular price
$64.95
Regular price
Sale price
$64.95

Vendor : DS18

Hurry! Only
0
units left in stock!
SATISFACTION
Guaranteed with effortless returns
DELIVERY
We ship to the contiguous 48 United States
PAYMENTS
Your security is our priority
WE ACCEPT
PayPal, Venmo & all major Credit Cards
  • 6X9" Mid-Range
  • MAX Power: 500 Watts
  • RMS Power: 250 Watts
  • Impedance: 2-Ohm
  • Ferrite Magnet
  • Shallow, Water Resistant

TECHNICAL DATA


SPECS

SKU
RPRO-SM69.2D
Nominal Diameter
6x9" / 152.4 mm x 228.6 mm
Nominal Impedance
2 OHMS
RMS Power Handing
250 Watts
Maximum Power Handing
500 Watts
Sensitivity (1w/1m)
96 dB
Frequency Response
60 Hz-5 Khz
Recommended Hi Pass Crossover
120 Hz


SPECS

Voice Coil Diameter
1.5" / 38.1 mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Basket Material
Steel
Magnet Weight
33 Oz


THIELE & SMALL PARAMETERS

Vas
10.147 L
Xmax
6.7 mm
Fs
110 Hz
Qms
7.358
Qes
0.959
Qts
0.848
Re
2 OHMS


MEASUREMENTS

Overall Diameter
9.25" x 6.57" / 235 mm x 167 mm
Front Mount Baffle Cutout
8.6" x 6" / 220 mm x 152 mm
Mounting Depth
2.68" / 68 mm
Overall Depth
2.91" / 74 mm
Product Weight
5.5 lbs
Product Dimensions
10 x 7.25 x 4
M/C Weight
44.5 lbs
M/C Dimensions
20.75 x 15.25 x 9
M/C QTY
8
Sold In
Piece

PRODUCT OVERVIEW


DS18 PRO-SM69.2


6x9" Shallow Water Resistant Mid-Range Loudspeaker 500W 2-Ohm

As a rider, you know the open-air environment comes with a set of challenges for your motorcycle’s audio system: but, the team of engineers at DS18 has crafted a solution that will take your motorcycle’s audio to new heights: introducing DS18’s PRO-SM69.2.
Crafted with meticulous attention to detail, the PRO-SM69.2 features premium materials that contribute to its exceptional performance. The PRO-SM69.2 boasts a water-resistant cone, ensuring that rain or water splashes won't dampen your audio experience. The cloth edge surround enhances sound accuracy and durability, while the red steel basket provides a sturdy foundation for optimal sound reproduction. The non-pressed water-resistant paper cone guarantees excellent audio clarity and resilience, even in challenging conditions. The 1.5" voice coil size and 33 oz magnet further contribute to the speaker's impressive performance, ensuring every note is delivered with precision and power.
With power handling capability of 500W MAX, the PRO-SM69.2 delivers thunderous sound that will captivate your senses. Its 2-ohm single voice coil allows you to maximize your amplifier's power level at the lowest resistance, eliminating the need for bridging. Experience audio at its peak, even when cruising at 60 miles per hour down the highway. The PRO-SM69.2 ensures your music cuts through the wind and engine noise, providing a full and rich sound that will keep you energized throughout your journey.
Installing the PRO-SM69.2 is a breeze, thanks to its manageable mounting depth of 2.68" and a front mount baffle cut-out dimension of 8.6x6". Within minutes, you'll have these powerful speakers seamlessly integrated into your motorcycle, ready to transform your audio experience.
DS18’s PRO-SM69.2 is the ultimate audio upgrade for motorcycle enthusiasts who demand nothing but the best.
