DS18 PRO 6.5" Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm (Single Unit)

No review yet. Write Review
Regular price
$94.95
Regular price
Sale price
$94.95

Vendor : DS18

Hurry! Only
0
units left in stock!
SATISFACTION
Guaranteed with effortless returns
DELIVERY
We ship to the contiguous 48 United States
PAYMENTS
Your security is our priority
WE ACCEPT
PayPal, Venmo & all major Credit Cards
  • 6.5" Mid-Range
  • RMS Power: 225 Watts
  • Impedance: 4-Ohm
  • Ferrite & Neodymium Magnets
  • With Built in Driver
  • Water Resistant IPX5

TECHNICAL DATA


SPECS

SKU
RPRO-HY6.4BD
Nominal Diameter
6.5" / 165.1mm
Nominal Impedance
4 Ohm
RMS Power Handling
225W
MAX Power Handling
450W
Sensitivity (1w/1m)
96dB
Frequency Response
100Hz - 20Khz
Recommended HI Pass Crossover
120Hz
Number of ways
2 ways
Pair or Single
Single
Grill Included
Yes


WOOFER SPECIFICATIONS

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Glass Fiber
Winding Material
CCAW
Cone Material
Water Resistant Paper (IPx5)
Surround Material
Cloth
Basket Material
Aluminum
Basket Color/Finish
Glossy Red
Magnet Material
Ferrite
Magnet Weight
27 Oz
Displacement Volume
0.047L / 0.0016ft3


THIELE & SMALL PARAMETERS

Equivalent Volume Vas
2.21L / 0.078ft3
Excursion (one way) Xmax
9.2mm
Free Air Resonance Fs
199Hz
Mechanical Factor Qms
5.96
Electrical Factor Qes
1.524
Total Factor Qts
1.214
Mechanical Mass Mms
8.654g
Mechanical Compliance Cms
73.792 mm/N
BL Factor BL
4.769
Voice Coil Inductance Le
4.22mH
Cone Area Sd
145.26 Cm2
DC Resistance Re
3.2 ohms
Mechanical Mass w/o air Mmd
6.70g


DRIVER SPECIFICATIONS

Voice Coil Diameter
1" / 25.4mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Diaphragm Material
Titanium
Magnet Material
Neodymium
Horn Diameter
3" / 76.2mm


SPEAKER MEASUREMENT

Overall Diameter
6.85" / 174mm
Overall Depth
4.28" / 108.8mm
Front Mount Baffle Cutout
5.91" / 150mm
Mounting Depth
3.92" / 99.5mm
Motor Diameter
4.65" / 118mm


SHIPPING INFO

Gross Single Unit Weight
5
Single Unit Box Dimensions L x W x H (Inches)
7.25 x 7.5 x 5
Quantity of Units in Master Carton
8
Gross Master Carton Weight
42.5
Master Carton Dimensions L x W x H (Inches)
15.75 x 15.75 x 10.25

PRODUCT OVERVIEW


DS18 PRO-HY6.4B


6.5" Water Resistant Mid-Range Loudspeaker with Built-in Driver 450 Watts 4-Ohm

Breaking barriers and defying conventional audio limitations, DS18's PRO-HY6.4B Hybrid speakers bring you the best of both worlds.
Designed to conquer the elements, the PRO-HY6.4B boasts water-resistant paper cones that effortlessly battle against nature's forces. Whether you're cruising on a motorcycle, navigating the open waters on a boat, or enjoying the ride in your trusty vehicle, these speakers are built to withstand the harshest conditions, all while maintaining peak performance.
The PRO-HY6.4B’s feature a high-volume 6.5" speaker and a 1" voice coiled driver, both rated at an astonishing 225W RMS and 450W MAX power handling. With a sensitivity of 96dB and a frequency response ranging from 100Hz to 20KHz, these speakers deliver crystal-clear sound reproduction across the entire audible spectrum.
DS18's PRO-HY6.4B driver boasts a diaphragm crafted from titanium, renowned for its remarkable stiffness-to-weight ratio. This premium material guarantees extraordinary clarity, allowing you to hear every nuance and detail in your favorite music with pristine accuracy. The driver's magnet material is none other than neodymium, a powerful and lightweight material that ensures superior control and response.
Every detail matters in the construction of the PRO-HY6.4B’s: its voice coil diameter of 1.5" and former made of glass fiber guarantee impeccable performance and durability. The cone, crafted from water-resistant paper, ensures longevity and resistance against the elements. The cloth surround, aluminum basket, and glossy red finish all contribute to an exquisite aesthetic that perfectly complements the exceptional audio quality.
Elevate your car audio system to new heights and let the PRO-HY6.4B redefine your audio expectations.
